Three Wings Pile Expansion Belling Bucket For Enlarging and Expanding Bored Piles Wall Bottom

Introduction:

1-The bearing capacity of bored piles can be increased significantly by enlarging the base area of a pile. Belling buckets are the right tools for base enlargement in stable ground conditions (mainly cohesive).
2-By using the leverage system and application of vertical crowd force on the push rod, the cutting arms are gradually opened. The drilled material falls into the open shell of the bucket. The cutting arms are closed by upward movement of the kelly bar which transmits the pull onto the push rod.

To improve the bearing capacity of the bottom of the bored piles, widen and expand the bottom of the foundation bored piles, customers can choose to expand the entire pile diameter or the bottom of the pile.

We have three types of piles bottom expansion buckets to choose from, suitable for different pile diameter enlarge purposes and different construction site strata.
The first type: Three-wing pile expansion bucket


Pile expansion diagram （how it works）


The second type: Double-bottom pile expansion drilling bucket
Conventional three-wing pile enlarging drill buckets need to be used with straight drill buckets together, and can only do the pile expanded work after the flat drilling bucket have driven the pile, that's to say, you need to constantly change the drilling bucket while do the pile piling and pile expansion work. The advantage of our this kind double bottom pile enlarging piling bucket is that it can expand the pile diameter whild drilling the piles, it can greatly improve site efficiency. In the picture below you can see how our this pile expansion drilling bucket works.


The third type: Double wing pile bottom expansion bucket

Parameters of Bi-cut Belling Bucket:

1-Cutting arms of JZTG Golden Drilling Belling Bucket can be adjustable, that could meet the specific requirements of different enlarge diameters for the borehole drilling;
2-After enlarging the borehole piling diameter, rock drilling bucket, soil drilling bucket can be used to convey spoil.;
3-The rotating cutting arms are easy to spread and retract, easy operation and high efficiency;
4-Application: for improving the bearing capacity of the pile bottom, suitable for clay, silt, frozen, medium soft rock, dense gravel, cobble...

Model of drilling teeth for choose:
B47K series (B47K17.5H, B47K19H, B47K22H), B85, B43H, Other JZTG drilling teeth: 55-22T, 60-26T, 55-22S, 60-24S, 55-10K22, 60-12K24, et (pictures and parameters please check our drilling teeth introduction).

JZTG Golden Drilling Workshop Show:

JZTG Golden Drilling New Factory Show:

For other details contact JZTG freely.
